Termék adatlap (PDF)
Leírás
Inputs: 1x HDMI: 19-Pin Type A
Outputs: 8x HDMI Out: 19-pin type A | 1x 3-pin Phoenix | S/PDIF
Video Encoding: Uncompressed 18Gbps
End to End Latency: None
Audio Formats: 2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos
Video Resolution (Max):
1920x1080p @60Hz 16bit
3840x2160p @60Hz 10bit 4:2:2 HDR10/10+
3840x2160p @60Hz 12bit 4:2:0 Dolby Vision
3840x2160p @50Hz 10bit 4:2:0 HLG
4096x2160p @60Hz 8bit 4:4:4
Supported Standards: DCI | RGB | HDR10 | HDR 10+ | Dolby Vision | HLG | BT.2020
Maximum Pixel Clock: 600Mhz
COMMUNICATION & CONTROL: HDCP 2.2 | EDID, RS-232
Power Supply: 12V DC 1A
Max Power Consumption: 6.73W
