Leírás
Dynamic visually lossless compression enables extension of up to 4K/60 4:4:4 or HDR 60Hz content over HDBaseT™ HDBaseT™ Class B transmission of 4K up to 35m/115ft and 1080p up to 70m/230ft Compatible with the latest HDR standards, including HDR-10+, HLG content, with support for Dolby Vision™ up to 30Hz Supports all VESA resolutions within the HDMI 2.0 specification Advanced re-clocking chipset increases compatibility with new 4K UHD source devices Bidirectional IR and RS-232 pass-through Supports CEC communication between devices* Slimline 21mm/0.83in chassis for easier, more convenient installation behind displays 2-way PoH (Power over HDBaseT™) enabling either transmitter or receiver to be remotely powered by the other unit. Supports 2ch PCM and 7.1 multichannel audio up to DTS:X and Dolby Atmos HDCP 2.2 compliant Automatic EDID Management (copy from RX-TX) Threaded bushings allow use of both standard and locking DC power plugs Visual LED indication for power supply to units, signal status to show established display connection, HDCP presence in signal and HDBaseT™ link between devices Automatically adjusts equalization and amplification of signal for easy installation Energy efficient universal power supply included
