INPUT: 1 composite video, 1Vpp/75Ω on a BNC connector.
OUTPUT: 1 composite video, 1Vpp/75Ω on a BNC connector.
INSERTION LOSS: 0.8dB.
MAX. OUTPUT LEVEL: 4Vpp/75Ω.
BANDWIDTH (-3dB): 5.8MHz.
DIFF. GAIN: 0.05%.
DIFF. PHASE: 0.05Deg.
K-FACTOR: 1.2%.
S/N RATIO: 73.4dB.
TILT: 0.1%.
NON-LINEARITY: 0.1%.
COUPLING: Transformer.
POWER CONSUMPTION: None, passive device.
DIMENSIONS: 12cm x 7.3cm x 3cm (4.7" x 2.88" x 1.2") W, D, H.
WEIGHT: 0.34kg (0.75lbs) approx.
