INPUTS: 1 unbalanced stereo audio on RCA connectors; 1 balanced stereo audio on a 5-pin terminal block connector.
OUTPUT: 1 stereo loudspeaker output on a 4-pin terminal block connector.
OUTPUT POWER: 8.4W RMS per channel into a 4Ω load.
OUTPUT MUSIC POWER: 35W RMS per channel into a 4Ω load.
BANDWIDTH (-3dB): 24kHz.
S/N RATIO: 55dB.
CONTROLS: Gain: -40dB to +19dB until the compression threshold.
COUPLING: Input: AC; speakers out: DC.
AUDIO THD + NOISE: 0.5% @1kHz.
AUDIO 2nd HARMONIC: 0.04% @1kHz.
POWER CONSUMPTION: 12V DC, 2.1A.
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H.
WEIGHT: 0.3kg (0.66lbs) approx.
INCLUDED ACCESSORIES: Power supply, mounting bracket.
